🔋 Pro-Range A Grade INR 21700-P45B 14.8V 22500mAh 10C 4S5P 180A/225A Discharge Li-ion Drone Battery Pack
By DB&C BY LOFTY AGROTECH
-
The 14.8V 22500mAh 4S5P Li-ion Drone Battery is a high-capacity lithium-ion battery pack engineered specifically for professional UAV and agricultural drone platforms.
-
Designed using premium A-Grade INR 21700-P45B cylindrical cells, the 14.8V 22500mAh 4S5P Li-ion Drone Battery delivers superior energy density and high discharge capability.
-
The 4S5P configuration of the 14.8V 22500mAh 4S5P Li-ion Drone Battery ensures stable voltage output and enhanced current handling performance.
-
With a nominal voltage of 14.8V, the 14.8V 22500mAh 4S5P Li-ion Drone Battery is compatible with most 4S UAV propulsion systems.
-
The 22500mAh capacity allows the 14.8V 22500mAh 4S5P Li-ion Drone Battery to support extended flight missions and heavy payload operations.
-
Manufactured and supplied by DB&C BY LOFTY AGROTECH, this battery pack is optimized for real-world drone field conditions.
🔹 Electrical Specifications & Performance
-
Nominal Voltage: 14.8V
-
Nominal Capacity: 22500mAh
-
Configuration: 4S5P
-
Discharge Rate: 10C
-
Continuous Discharge Current: 180A
-
Peak Discharge Current: 225A
-
Maximum Charging Voltage: 16.8V
-
Maximum Discharging Voltage: 11.6V
-
Charging Current: Up to 5C
-
BMS: No (External BMS Compatible)
The 14.8V 22500mAh 4S5P Li-ion Drone Battery is engineered to deliver consistent voltage output even under heavy throttle demand, making it ideal for commercial UAV fleets.
🔹 Advanced 4S5P Configuration Benefits
-
The 4S design of the 14.8V 22500mAh 4S5P Li-ion Drone Battery ensures optimal 14.8V system compatibility.
-
The 5P parallel grouping significantly increases discharge capability.
-
Load distribution across five parallel cell groups reduces stress on individual cells.
-
The architecture enhances lifespan and reduces internal heating.
-
The 14.8V 22500mAh 4S5P Li-ion Drone Battery maintains stable power during aggressive lift operations.
🔹 High Discharge Power Capability
-
10C discharge rate supports high-demand UAV propulsion.
-
180A continuous discharge ensures sustained motor performance.
-
225A peak discharge enables emergency power bursts.
-
The 14.8V 22500mAh 4S5P Li-ion Drone Battery prevents excessive voltage sag during high throttle input.
-
Ideal for agricultural drones carrying liquid spray tanks.
-
Provides stable thrust during take-off with full payload.
🔹 Premium INR 21700-P45B Cell Technology
-
The 14.8V 22500mAh 4S5P Li-ion Drone Battery uses A-Grade cylindrical cells.
-
Improved mechanical durability compared to pouch cells.
-
Enhanced thermal resistance.
-
Reduced swelling risk.
-
Lower internal resistance improves efficiency.
-
Stable performance across multiple charge cycles.
🔹 Thermal Stability & Heat Management
-
Cylindrical cell spacing improves airflow inside the 14.8V 22500mAh 4S5P Li-ion Drone Battery.
-
Better heat dissipation compared to traditional Li-Po batteries.
-
Suitable for high-temperature agricultural environments.
-
Reduced overheating risk during long missions.
-
Designed for repetitive high-discharge cycles.
🔹 Extended Flight Time Advantage
-
The 22500mAh capacity significantly improves mission endurance.
-
The 14.8V 22500mAh 4S5P Li-ion Drone Battery supports longer spray cycles.
-
Ideal for mapping and surveying large land areas.
-
Reduced battery swaps during field operations.
-
Improves operational efficiency for commercial drone operators.
🔹 Connector & Charging System
-
5 Pin JST XH balance connector ensures accurate cell balancing.
-
Amass XT90 AS anti-spark discharge connector enhances safety.
-
Supports fast charging up to 5C.
-
The 14.8V 22500mAh 4S5P Li-ion Drone Battery minimizes downtime between missions.
-
Compatible with professional lithium-ion chargers.
🔹 Mechanical Design & Build Quality
-
Length: 125 mm
-
Width: 95 mm
-
Height: 80 mm
-
Weight: Approx. 1840g
-
Reinforced structural assembly.
-
High-current nickel strip welding.
-
Secure insulation layers.
-
Designed to withstand drone frame vibration.
🔹 Applications
The 14.8V 22500mAh 4S5P Li-ion Drone Battery is ideal for:
-
Agricultural spray drones
-
Fertilizer spreading UAVs
-
Industrial inspection drones
-
Surveillance UAV systems
-
Survey and mapping drones
-
Heavy-lift quadcopters
-
Custom UAV builds
⭐ Key Features of 14.8V 22500mAh 4S5P Li-ion Drone Battery
-
A-Grade INR 21700-P45B Cells
-
10C High Discharge Rating
-
180A Continuous Output
-
225A Peak Output
-
4S5P Configuration
-
22500mAh High Capacity
-
XT90 Anti-Spark Connector
-
JST XH Balance Port
-
Fast Charging Support (5C)
-
External BMS Compatible
-
Durable Cylindrical Cell Design
-
Optimized for UAV Systems
-
High Thermal Stability
-
Long Operational Life
🔬 Operational Efficiency Benefits
-
Reduced voltage drop during flight.
-
Consistent motor RPM stability.
-
Improved ESC longevity.
-
Stable output for flight controllers.
-
Reliable performance during hover operations.
-
Better energy conversion efficiency.
-
Suitable for high-throttle aerial maneuvers.
🛠 Maintenance & Best Practices
To maximize performance of the 14.8V 22500mAh 4S5P Li-ion Drone Battery:
-
Avoid discharging below 11.6V.
-
Always balance charge.
-
Store at 40–60% charge when not in use.
-
Avoid overcharging beyond 16.8V.
-
Keep battery in cool, dry environment.
-
Use compatible lithium-ion charger.
🌟 Why Choose LOFTY AGROTECH
Choosing LOFTY AGROTECH means choosing reliability, engineering precision, and long-term performance.
✅ 1. A-Grade Cell Selection
-
Only premium INR 21700-P45B cells are used.
-
Each 14.8V 22500mAh 4S5P Li-ion Drone Battery undergoes quality verification.
✅ 2. UAV-Specific Engineering
-
Designed specifically for drone propulsion systems.
-
Tested under real UAV load conditions.
-
Optimized for agricultural field environments.
✅ 3. Strict Quality Control
-
Voltage testing before dispatch.
-
Internal resistance matching.
-
Load testing for discharge stability.
-
Batch consistency maintained.
✅ 4. Bulk & OEM Capability
-
Custom branding available.
-
Large-volume supply capability.
-
Custom capacity configurations supported.
-
Reliable export packaging.
✅ 5. Performance Reliability
-
Stable discharge output.
-
Reduced internal heating.
-
Enhanced structural durability.
-
Long cycle life.
✅ 6. Trusted Industry Partner
-
Serving agricultural drone manufacturers.
-
Supporting industrial UAV integrators.
-
Providing technical guidance for integration.
📌 Final SEO Summary
The 14.8V 22500mAh 4S5P Li-ion Drone Battery by DB&C BY LOFTY AGROTECH is a high-capacity, high-discharge lithium-ion battery engineered for demanding UAV operations. With a 10C rating, 180A continuous output, and 225A peak discharge capability, the 14.8V 22500mAh 4S5P Li-ion Drone Battery delivers reliable power for agricultural, industrial, and commercial drone platforms.
If you require extended flight time, stable voltage performance, and professional-grade durability, the 14.8V 22500mAh 4S5P Li-ion Drone Battery from LOFTY AGROTECH is the ideal solution.
🔹 Energy Density & Power Optimization
-
The 14.8V 22500mAh 4S5P Li-ion Drone Battery is engineered to maximize energy storage while maintaining safe thermal limits.
-
High energy density ensures longer operational flight cycles for UAV systems.
-
Compared to lower capacity packs, the 14.8V 22500mAh 4S5P Li-ion Drone Battery delivers improved runtime efficiency.
-
The 4S5P structure enables optimal voltage regulation and high current output simultaneously.
-
The 14.8V 22500mAh 4S5P Li-ion Drone Battery reduces performance drop during heavy throttle usage.
🔹 Load Balancing & Electrical Stability
-
Five parallel cell groups distribute current evenly across the 14.8V 22500mAh 4S5P Li-ion Drone Battery.
-
Reduced internal resistance improves electrical efficiency.
-
The 14.8V 22500mAh 4S5P Li-ion Drone Battery maintains steady voltage under fluctuating flight loads.
-
Stable current flow protects ESCs and motors from sudden voltage dips.
-
Consistent output enhances drone flight precision.
🔹 High-Throttle & Heavy Payload Performance
-
The 14.8V 22500mAh 4S5P Li-ion Drone Battery is ideal for agricultural drones carrying spray tanks.
-
Provides strong lift capability during full tank take-off.
-
Maintains reliable thrust during wind compensation.
-
The 14.8V 22500mAh 4S5P Li-ion Drone Battery supports sustained high RPM motor performance.
-
High peak discharge allows emergency lift or obstacle avoidance maneuvers.
🔹 Improved ROI for Commercial Drone Fleets
-
Longer flight times reduce battery swap frequency.
-
Reduced downtime improves mission productivity.
-
The 14.8V 22500mAh 4S5P Li-ion Drone Battery supports faster recharge cycles (up to 5C).
-
Durable cylindrical cell design increases overall lifecycle value.
-
Lower replacement frequency improves cost efficiency for commercial operators.
🌾 Agricultural Mission Optimization
The 14.8V 22500mAh 4S5P Li-ion Drone Battery is particularly suited for:
-
Crop spraying operations
-
Fertilizer distribution
-
Precision agriculture mapping
-
Plantation monitoring
-
Large-scale farmland coverage
Benefits in agricultural operations:
-
Stable voltage during pump operation
-
Reliable performance in high-temperature outdoor environments
-
Reduced voltage sag during full payload takeoff
-
Smooth hover stability for uniform spray coverage
🔥 Thermal & Structural Reliability
-
Cylindrical INR 21700-P45B cells inside the 14.8V 22500mAh 4S5P Li-ion Drone Battery enhance heat dissipation.
-
Reduced risk of swelling compared to pouch cells.
-
Strong internal nickel strip connections for high-current flow.
-
Insulated and reinforced structural assembly.
-
Designed to withstand vibration stress from drone motors.
📈 Performance Consistency Across Cycles
-
The 14.8V 22500mAh 4S5P Li-ion Drone Battery maintains consistent output over repeated charge cycles.
-
Balanced cell architecture improves lifespan.
-
Voltage stability remains reliable when operated within safe limits.
-
Suitable for frequent daily commercial drone missions.
-
Long-term capacity retention improves investment value.
🛡 Safety & Operational Recommendations
To ensure optimal performance of the 14.8V 22500mAh 4S5P Li-ion Drone Battery:
-
Use compatible lithium-ion charger only.
-
Do not exceed 16.8V during charging.
-
Avoid discharging below 11.6V.
-
Always balance charge using JST XH connector.
-
Store at partial charge when not in use.
-
Protect from moisture and physical impact.
💼 Fleet Deployment Advantages
For drone manufacturers and agricultural service providers:
-
The 14.8V 22500mAh 4S5P Li-ion Drone Battery offers batch consistency.
-
Suitable for fleet standardization.
-
Reliable discharge output ensures uniform drone performance across multiple units.
-
Simplifies operational logistics for drone service companies.
-
Compatible with professional 4S UAV propulsion systems.
🌟 Expanded Why Choose LOFTY AGROTECH
Choosing LOFTY AGROTECH means partnering with a drone power specialist focused on performance and reliability.
✅ Precision Manufacturing
-
Each 14.8V 22500mAh 4S5P Li-ion Drone Battery is assembled with strict quality control.
-
Cells are matched for voltage consistency and internal resistance.
✅ UAV-Focused Product Design
-
Designed specifically for aerial platforms.
-
Tested under real drone load simulations.
-
Optimized for agricultural drone environments.
✅ Consistent Performance Standards
-
Every 14.8V 22500mAh 4S5P Li-ion Drone Battery undergoes:
-
Voltage verification
-
Discharge testing
-
Structural inspection
-
✅ OEM & Bulk Supply Support
-
Custom labeling available.
-
Large-scale production capability.
-
Reliable export packaging.
-
Consistent lead times.
✅ Long-Term Reliability
-
Stable discharge performance.
-
Reduced thermal stress.
-
Enhanced structural durability.
-
Suitable for intensive commercial usage.
