Description



DYS F722 Flight Controller with ICM42688P – Ultimate FPV Drone Performance

The DYS F722 Flight Controller  with ICM42688P is a high-performance flight controller designed for advanced FPV drones and multi-rotor UAVs. Combining the powerful STM32F722 microcontroller with the ICM42688P gyroscope, BMP280 barometer, and AT7456E OSD chip, this controller ensures exceptional stability, rapid response, and full telemetry integration. Ideal for FPV racing, freestyle drones, aerial photography, and experimental DIY projects, the DYS F722 Flight Controller ICM42688P offers both versatility and precision for professionals and hobbyists alike.

---

Overview of DYS F722 Flight Controller with ICM42688P

The DYS F722 Flight Controller with ICM42688P is engineered to deliver reliable and responsive flight performance. Its STM32F722 processor allows high-speed PID loop calculations, ensuring precise flight stability even during high-G maneuvers. The integrated ICM42688P gyroscope provides accurate motion sensing, while the BMP280 barometer supports altitude hold and autonomous flight features. Additionally, the AT7456E OSD chip overlays telemetry data directly on your FPV feed, giving pilots instant access to battery voltage, current, flight time, and other critical parameters.

The flight controller supports up to 8 ESC outputs and 6 UART ports, making it suitable for complex multi-motor drones and advanced peripheral setups. With a compact 38mm × 38mm form factor, standard 30.5mm mounting holes, and support for 6S LiPo batteries, the DYS F722 Flight Controller with ICM42688P fits most modern FPV frames while offering extensive connectivity options.

---

Why DYS F722 Flight Controller with ICM42688P Stands Out

The DYS F722 Flight Controller  with ICM42688P is a high-performance solution designed for competitive FPV racing, freestyle flying, aerial photography, and advanced DIY drone projects. It differentiates itself from conventional F7 flight controllers through a combination of ultra-fast processing, low-latency motion sensing, and integrated OSD functionality. Its robust design and versatile connectivity make it an ideal choice for pilots seeking precision, reliability, and advanced telemetry in a compact package.

High-Speed STM32F722 Processor

At the core of the DYS F722 Flight Controller  with ICM42688P lies the STM32F722 ARM Cortex-M7 microcontroller, a high-performance 32-bit processor engineered for real-time control and advanced computations. Key benefits include:

• Rapid PID Loop Execution: The processor supports high-speed PID calculations, enabling extremely responsive flight behavior, essential for racing and freestyle drones.
• Stable Sensor Fusion: Integrates data from the ICM42688P gyroscope and accelerometer efficiently, reducing latency and providing smooth flight even during aggressive maneuvers.
• Real-Time OSD Updates: Supports simultaneous flight telemetry overlay on FPV feeds without causing lag or interruptions.
• Enhanced Algorithm Support: Allows pilots to use advanced Betaflight features, including dynamic filtering, anti-gravity modes, and custom flight profiles.

With these capabilities, pilots experience near-instant response to stick inputs, making the DYS F722 Flight Controller ICM42688P ideal for high-speed and precision flying.

Precision ICM42688P Gyroscope

The ICM42688P 6-axis motion sensor integrated into the DYS F722 Flight Controller  with ICM42688P combines a high-precision gyroscope and accelerometer in a single module. Its advantages include:

• Accurate Stabilization: Ensures precise orientation control and improved flight stability during sharp turns, flips, and rolls.
• Low-Noise Performance: Minimizes signal interference for smoother flight, particularly in aggressive or high-speed maneuvers.
• Enhanced Responsiveness: Allows pilots to maintain control in challenging conditions, such as turbulent airflow or rapid directional changes.

This sensor provides reliable data for real-time flight adjustments, making it suitable for FPV racing, freestyle aerial tricks, and professional UAV applications.

 BMP280 Barometer for Altitude Control

Altitude management is crucial for stable aerial footage and autonomous flight. The BMP280 barometer in the DYS F722 Flight Controller with ICM42688P provides:

• Precise Altitude Measurement: Enables altitude hold for smooth hovering and consistent flight paths.
• Autonomous Flight Support: Works with GPS modules and Betaflight features for autonomous waypoint navigation.
• Cinematic Stability: Helps maintain steady camera angles during aerial photography and videography.
• Optimized PID Tuning: Allows fine adjustments of altitude control loops, improving overall flight precision.

This barometer ensures that drones maintain steady altitude, even during aggressive flight maneuvers or wind interference.

 Integrated AT7456E OSD

On-screen display is essential for FPV pilots who need telemetry data in real-time. The AT7456E OSD chip embedded in the DYS F722 Flight Controller  with ICM42688P offers:

• Real-Time Telemetry Overlay: Displays battery voltage, current draw, flight duration, signal strength, and other critical data directly on the FPV feed.
• Simplified Wiring: Eliminates the need for additional external OSD modules, reducing weight and clutter.
• Customizable Layout: Pilots can configure the OSD display using Betaflight Configurator to match personal preferences or frame layouts.
• Integrated Flight Monitoring: Improves situational awareness and helps prevent power-related failures or telemetry loss.

With integrated OSD, pilots gain instant insight into flight status, enhancing both safety and control during complex maneuvers.



Technical Specifications of DYS F722 Flight Controller with ICM42688P

The DYS F722 Flight Controller  with ICM42688P is engineered with cutting-edge hardware and design to meet the demands of high-performance drones, FPV racing, freestyle flying, and professional UAV applications. Below is a detailed breakdown of its key technical specifications:

Microcontroller and Sensors

The heart of the DYS F722 Flight Controller with ICM42688P is the STM32F722 microcontroller, a 32-bit ARM Cortex-M7 processor that delivers ultra-fast computation and responsive flight control. Its high processing power enables:

• Real-time PID loop calculations for precise stability during aggressive maneuvers.
• Low-latency sensor fusion for smoother handling and reduced oscillations.
• Support for advanced flight features and firmware like Betaflight.

The controller integrates the ICM42688P, a high-precision 6-axis motion sensor combining a gyroscope and accelerometer. This sensor provides:

• Accurate orientation detection for tight turns, flips, and rolls.
• Noise reduction for smoother and stable flights in racing and freestyle applications.

Additionally, the BMP280 barometer allows precise altitude measurements, enabling altitude hold and advanced autonomous flight functions. The AT7456E OSD chip offers real-time telemetry overlay on the FPV feed, including battery voltage, current, flight time, and sensor data, reducing the need for additional wiring.

Power and Connectivity

The DYS F722 Flight Controller with ICM42688P is designed for versatility in powering peripherals and integrating multiple modules:

• BEC Outputs: Provides stable 3.3V/1A, 5V/3A, and 12V/3A for cameras, VTX, LEDs, and other accessories.
• Battery Support: Compatible with 6S LiPo batteries for extended flight times and high power demand builds.
• ESC Outputs: 8 channels support multi-rotor setups, including octocopters and high-end FPV drones.
• UART Ports: 6 UART ports facilitate connections to GPS modules, telemetry radios, receivers, and other peripherals, enabling flexible customization for complex setups.

This connectivity ensures pilots can integrate all necessary systems while maintaining clean wiring and efficient power distribution.

Logging and Data Storage

The 16MB onboard black box allows comprehensive flight data recording:

• Stores motor outputs, sensor data, PID responses, and other critical flight parameters.
• Enables post-flight analysis for advanced PID tuning and performance optimization.
• Helps diagnose flight anomalies and improve drone reliability over time.

Black box logging is essential for both competitive FPV pilots seeking performance gains and hobbyists learning flight dynamics.

 Physical Dimensions

The DYS F722 Flight Controller ICM42688P features a compact and lightweight form factor designed for versatility:

• Size: 38mm × 38mm, suitable for most FPV and custom drone frames.
• Mounting Holes: Standard 30.5mm spacing allows easy installation and stackable integration with 4-in-1 ESCs or PDBs.
• Weight: Minimal, preserving drone agility and overall flight performance.

This compact design ensures the controller fits into tight builds without compromising functionality, making it ideal for racing quads, freestyle drones, and advanced multi-rotor UAVs.

---



Advantages of DYS F722 Flight Controller  with ICM42688P

The DYS F722 Flight Controller with ICM42688P is designed to provide drone pilots with maximum control, flexibility, and reliability. Its advanced hardware and thoughtful design deliver measurable benefits across FPV racing, freestyle flying, aerial photography, and educational projects.

Responsive Flight Performance

Equipped with the STM32F722 microcontroller and ICM42688P gyroscope, the DYS F722 Flight Controller with ICM42688P delivers ultra-fast PID loop calculations and precise sensor feedback. This translates into:

• Immediate reaction to stick inputs, enhancing control during high-speed flight.
• Smooth stabilization during aggressive maneuvers, flips, and rolls.
• Reduced drift and oscillation in all flight modes, including GPS-assisted or autonomous flight.

Pilots experience a responsive, reliable, and safe flight, even in challenging conditions or tight racing circuits.

versatile Power Management

The DYS F722 Flight Controller ICM42688P features multiple BEC outputs (3.3V/1A, 5V/3A, and 12V/3A) to efficiently power onboard electronics. Benefits include:

• Ability to power cameras, VTX modules, LEDs, and sensors without additional power distribution boards.
• Reduced weight and clutter in the drone build.
• Stable voltage supply, preventing brownouts or unexpected shutdowns of peripherals during maneuvers.

This versatility allows pilots to configure their drone systems precisely without compromising flight stability.

Extensive Connectivity

With 6 UART ports and 8 ESC motor outputs, the DYS F722 Flight Controller ICM42688P supports complex and custom drone configurations:

• Connection of GPS modules, telemetry devices, and external sensors.
• Support for multi-rotor setups up to 8 motors.
• Seamless integration with PPM, SBUS, or serial protocol receivers.

This extensive connectivity makes it an ideal choice for professional builds, experimental drones, and high-performance FPV setups.

comprehensive Data Logging

The 16MB black box on the DYS F722 Flight Controller ICM42688P allows for:

• Recording of flight parameters including motor outputs, sensor data, and PID responses.
• Detailed post-flight analysis to optimize PID tuning and flight performance.
• Identification and correction of potential issues in both racing and freestyle drones.

This feature is invaluable for pilots seeking to refine their setups or for researchers studying flight dynamics.

 Compact and Lightweight

The 38mm × 38mm footprint with a minimal weight design ensures:

• Easy installation in tight or compact drone frames.
• Minimal impact on overall drone weight, preserving agility and maneuverability.
• Compatibility with stackable setups, allowing integration with ESCs and PDBs for clean, organized builds.

The combination of compact size and lightweight design makes the DYS F722 Flight Controller ICM42688P suitable for both mini quads and larger FPV builds, providing high-performance capabilities without adding unnecessary bulk.

---





Applications of DYS F722 Flight Controller  with ICM42688P

The DYS F722 Flight Controller ICM42688P is a versatile, high-performance controller designed for multiple drone applications. Its combination of the STM32F722 processor, ICM42688P sensor, BMP280 barometer, and AT7456E OSD makes it ideal for professional FPV pilots, aerial photographers, and educational users.

FPV Racing

FPV racing demands ultra-fast response times, precise stabilization, and low-latency sensor feedback. The DYS F722 Flight Controller ICM42688P meets these requirements by:

• High-Speed Processing: The STM32F722 CPU enables rapid PID loop calculations, reducing response delay and improving handling during high-speed maneuvers.
• ICM42688P 6-Axis Sensor: Provides precise orientation and stabilization, allowing the drone to maintain control in sharp turns, flips, and rolls.
• Low-Latency Telemetry: The AT7456E OSD displays real-time voltage, current, and flight time information directly in the FPV feed, ensuring pilots have critical data during competitive racing.
• Black Box Logging: Flight data recording allows racers to analyze performance and fine-tune PID and filter settings for optimized lap times.

Pilots using the DYS F722 Flight Controller ICM42688P gain a competitive edge with precise control, responsive handling, and consistent performance on challenging racecourses.

 Freestyle Flying

Freestyle flying requires smooth, acrobatic motion control for flips, rolls, and complex aerial tricks. The DYS F722 Flight Controller ICM42688P enhances freestyle capabilities by:

• Stable Flight Algorithms: Advanced sensor fusion from the ICM42688P gyroscope ensures smooth motion even during aggressive maneuvers.
• Black Box Analysis: Logging of flight data allows pilots to adjust PID and filter settings for personalized flight characteristics.
• Integrated BEC Outputs: Supplies reliable power to cameras, LEDs, and VTX systems during freestyle flights, avoiding voltage drops that could destabilize the drone.

With these features, freestyle pilots can confidently perform dynamic aerial tricks while maintaining precise control over their drones.

 Aerial Photography and Cinematography

Capturing smooth cinematic footage requires precise altitude control, stable orientation, and reliable power delivery. The DYS F722 Flight Controller ICM42688P is perfectly suited for aerial photography through:

• BMP280 Barometer: Provides accurate altitude measurements for steady hovering and altitude-hold functionality.
• AT7456E OSD: Displays flight telemetry such as battery voltage, current, and flight time on the FPV feed for continuous monitoring.
• Multiple BEC Outputs: 3.3V, 5V, and 12V outputs ensure consistent power to cameras, gimbals, and VTX modules without interference.
• 6 UART Ports: Facilitate connectivity with GPS modules, telemetry devices, and peripheral sensors to support autonomous or semi-autonomous flight modes.

This makes the DYS F722 Flight Controller ICM42688P ideal for filmmakers, photographers, and commercial UAV operators seeking reliable and precise flight control.

Educational and DIY Projects

The DYS F722 Flight Controller ICM42688P also serves as a powerful platform for learning and experimentation:

• Open-Source Firmware Compatibility: Supports Betaflight and other community-driven flight software, allowing students and hobbyists to explore programming, sensor data integration, and PID tuning.
• Sensor Data Access: The ICM42688P gyro and accelerometer, combined with the BMP280 barometer, enable in-depth study of flight physics and control algorithms.
• DIY Drone Builds: The compact 38 × 38 mm form factor with 30.5 mm mounting holes fits a variety of frames, making it suitable for custom multirotors, mini quads, and experimental UAV projects.
• Data Logging and Analysis: The 16MB black box records flight data for research, optimization, and academic experiments.

This combination of performance, connectivity, and versatility makes the DYS F722 Flight Controller ICM42688P an excellent tool for education, research, and hands-on learning in drone technology.

---



Installation and Wiring of DYS F722 Flight Controller with  ICM42688P

Proper installation and wiring are critical to ensure the DYS F722 Flight Controller ICM42688P performs optimally. This section details mounting, wiring, and firmware setup for both hobbyists and professional drone builders.

Mounting the Controller

The DYS F722 Flight Controller ICM42688P features standard 30.5 mm mounting holes, making it compatible with most FPV and racing drone frames. Its compact 38 × 38 mm design ensures easy integration into tight builds while maintaining stability.

Key considerations for mounting:

• Stackable Design: The board can be stacked on power distribution boards (PDBs) or 4-in-1 ESCs, allowing a neat and compact drone setup. This reduces frame clutter and keeps the center of gravity optimized for high-speed flight.
• Vibration Isolation: Use soft mounting grommets or rubber dampeners to reduce vibration interference on the ICM42688P gyroscope and BMP280 barometer, improving flight stability.
• Orientation: Ensure the flight controller arrow points forward in the frame for correct sensor alignment. Incorrect orientation can affect PID tuning, OSD display, and flight response.

Wiring Options

The DYS F722 Flight Controller ICM42688P offers flexible wiring for various peripherals, ensuring reliable connections without compromising drone performance:

• Solder Pads: For permanent, high-quality connections to ESCs, motors, and other critical components. Soldered joints ensure minimal signal loss and reliable current flow.
• Modular Connectors: Ideal for pilots who frequently swap or upgrade components. These connectors allow easy disassembly and maintenance without resoldering.
• Multiple UART Ports: With 6 UART ports, the controller supports receivers (PPM, SBUS, SUMD), telemetry modules, GPS units, and peripheral devices like LED controllers or OSD sensors. Proper assignment of UARTs in Betaflight ensures seamless communication.

Pro tip: Keep wiring short and tidy to reduce electromagnetic interference and prevent tangling with propellers or other moving parts.

Firmware Configuration

Firmware setup is essential for optimal flight performance and safety. The DYS F722 Flight Controller ICM42688P is compatible with Betaflight, allowing full customization:

• PID Tuning: Adjust PID loops according to drone type and pilot preference to achieve smooth, responsive flight.
• Flight Modes: Configure angle, horizon, and acro modes for freestyle, racing, or cinematic flying.
• OSD Layout: Using the AT7456E OSD, pilots can overlay critical flight information (voltage, current, flight time, RSSI) directly onto their FPV feed.
• Receiver Setup: Activate UARTs for serial receivers or enable RX_serial for PPM input. Proper configuration ensures that commands from your radio transmitter are accurately interpreted by the flight controller.
• Sensor Calibration: Calibrate the ICM42688P gyro and accelerometer, as well as the BMP280 barometer, for precise stabilization and altitude hold.

Following these installation and wiring steps ensures the DYS F722 Flight Controller ICM42688P delivers maximum performance, stable telemetry, and reliable power distribution for multi-motor FPV drones.

---



Quality Assurance of DYS F722 Flight Controller with ICM42688P

Quality and reliability are critical when it comes to high-performance flight controllers. The DYS F722 Flight Controller ICM42688P undergoes extensive testing to ensure it performs flawlessly under demanding conditions, giving pilots confidence in both casual and competitive UAV operations.

Rigorous Testing

The DYS F722 Flight Controller ICM42688P is subjected to multiple layers of rigorous testing before it reaches the end-user:

• High-Temperature Testing: Each unit is exposed to extreme heat to verify the stability and performance of electronic components under demanding environmental conditions. This ensures that the flight controller operates reliably during long flights in hot climates or under high-current draw conditions.
• Electrical Continuity Tests: All circuits, connectors, and onboard components undergo detailed electrical tests to confirm uninterrupted signal flow. This guarantees accurate communication between the STM32F722 microcontroller, IMU sensors, ESC outputs, and peripherals, minimizing the risk of in-flight failures.
• Mechanical Stress Testing: The board and its connectors are tested for repeated bending, vibration, and insertion/removal cycles. This ensures that the ICM42688P sensor, OSD, UART ports, and other components maintain structural integrity and durability during aggressive maneuvers, racing, or rough handling during installation.

These tests collectively ensure that each DYS F722 Flight Controller ICM42688P delivers consistent, high-quality performance throughout its operational life.

Trusted Performance

Backed by NDB&C by Lofty Agrotech, the DYS F722 Flight Controller ICM42688P meets professional standards for UAV performance and reliability. Each unit is carefully inspected to guarantee:

• Stable flight control across a wide range of drones, including FPV racers, freestyle quads, and aerial photography platforms.
• Accurate telemetry and sensor data for precise navigation, altitude control, and autonomous flight modes.
• Reliable power delivery through its multiple BEC outputs, ensuring connected devices such as cameras, VTX, and GPS modules function without interruptions.

By combining advanced engineering with strict quality protocols, the DYS F722 Flight Controller ICM42688P offers pilots a dependable, high-performance platform capable of handling the most demanding UAV applications.

---



Technical Comparison with Other Flight Controllers

When selecting a flight controller, pilots often compare processing power, sensor performance, connectivity, power management, and form factor. The DYS F722 Flight Controller ICM42688P excels in all these areas, making it a superior choice for FPV racing, freestyle, aerial photography, and DIY drone projects.

Higher Processing Speed (STM32F722 vs. STM32F405)

The STM32F722 microcontroller at the heart of the DYS F722 Flight Controller with ICM42688P delivers significantly higher clock speeds compared to older STM32F405-based controllers. This results in:

• Faster PID loop calculations, allowing the drone to react instantly to stick inputs.
• Improved flight stability even under aggressive maneuvers or turbulent conditions.
• Enhanced support for advanced flight algorithms such as dynamic filtering, anti-vibration processing, and autonomous flight features.

Pilots transitioning from STM32F405 controllers will notice smoother handling, reduced oscillations, and quicker response times, especially in high-speed FPV racing or freestyle flights.

Advanced 6-Axis ICM42688P Sensor for Precise Stabilization

Unlike older flight controllers that use MPU6000 or similar IMUs, the ICM42688P sensor offers:

• High-resolution gyroscope and accelerometer data for more precise flight control.
• Low-latency motion sensing, reducing the lag between pilot input and drone response.
• Improved vibration tolerance, which is critical for high-G maneuvers, racing, and acrobatic tricks.

This sensor ensures that the DYS F722 Flight Controller with ICM42688P maintains stable flight even under demanding conditions, giving pilots confidence in both freestyle acrobatics and autonomous flight operations.

 Larger Black Box Storage (16MB)

Flight data logging is a crucial feature for tuning and post-flight analysis. The 16MB black box on the DYS F722 Flight Controller ICM42688P offers:

• Extended recording capacity compared to controllers with smaller storage.
• Detailed PID and sensor data capture, allowing pilots to refine flight performance.
• Support for long-duration flights without running out of storage.

This makes the controller ideal for both hobbyists and professional pilots who want to analyze flights, optimize tuning, and improve consistency across multiple flights.

Multiple BEC Outputs and Higher Voltage Support

Power management is essential for drones with multiple peripherals. The DYS F722 Flight Controller ICM42688P provides:

• Multiple BEC outputs (3.3V/1A, 5V/3A, 12V/3A) to safely power cameras, VTX, GPS, and additional sensors.
• Support for 6S LiPo batteries, allowing for extended flight times and high-performance setups.
• Reduced wiring complexity, eliminating the need for separate voltage regulators or multiple power modules.

Compared to older F4 or F7 boards, this feature ensures more reliable power delivery, less voltage sag, and stable operation of all connected components.

 Compact Form Factor Suitable for Diverse Drone Builds

The 38mm × 38mm form factor with standard 30.5mm mounting holes ensures:

• Compatibility with mini quads, racing drones, and larger freestyle frames.
• Stackable integration with PDBs or 4-in-1 ESCs, reducing build complexity.
• Weight efficiency, adding minimal mass to the drone for better agility and flight dynamics.

This compact yet feature-rich design allows the DYS F722 Flight Controller with ICM42688P to be used across a wide variety of UAV projects, from small FPV racers to fully loaded photography drones.

---



Conclusion of DYS F722 Flight Controller with ICM42688P

The DYS F722 Flight Controller with ICM42688P is a top-tier flight controller designed for FPV enthusiasts, racers, photographers, and educational projects. With its STM32F722 microcontroller, ICM42688P gyroscope, BMP280 barometer, AT7456E OSD, 16MB black box, and multiple connectivity options, it provides unparalleled precision, flexibility, and reliability. Its compact design, stackable configuration, and robust power management make it an ideal choice for both professional and DIY drone builders. Backed by NDB&C by Lofty Agrotech, the DYS F722 Flight Controller with ICM42688P ensures consistent performance, durable construction, and easy integration into a wide range of drone platforms.

---

Link

 In stock now. Limited quantities available. Ships within 24 hours.

LOOKING FOR MORE? DISCOVER EVERYTHING WITH OFFER AT http://www.loftyagrotech.com

Explore more in our camera drone collection and find the right aerial companion.

Before flying, ensure you’re compliant with India’s drone regulations (DGCA DigitalSky Portal).
