Description
The EFT E620P Hexacopter Drone Kit sets a new standard in agricultural UAV technology with its impressive 20-liter spraying tank and heavy-lift design. Designed for professionals, it offers precise and efficient application of fertilizers, pesticides, and crop treatments, significantly improving agricultural productivity and sustainability.
With GPS navigation, waypoint automation, and a foldable design for easy transport, this drone is built to handle large fields with minimal manual intervention. The integrated power wiring system ensures reliable performance by reducing electrical interference.
Package Includes:
-
1 x E620P Drone Frame
-
1 x 20L Sprayer Tank
-
3 x Hobbywing X9 Motor (CW)
-
3 x Hobbywing X9 Motor (CCW)
-
3 x Drone Propeller (CCW)
-
3 x Drone Propeller (CW)
-
1 x 8L Brushless Pump
-
4 x Extended Spray Bars
-
1 x Universal Spray Pneumatic Bracket
-
1 x RTK Mount
-
1 x Front Radar Mount
-
1 x Height Radar Mount
Key Features:
-
Efficient Agricultural Spraying – 20L tank designed for large-scale fields.
-
Classic Folding Body – Easy to transport & deploy in the field.
-
Integrated Power Supply Wiring – Centralized design to reduce interference & simplify setup.
-
GPS-Enabled Navigation – Supports waypoint mapping for fully automated spraying missions.
-
Heavy Payload Capacity – Can carry up to 46.5 kg for maximum productivity.
-
High-Performance Brushless Pump – 8L brushless pump ensures steady spraying pressure.
-
Scalable & Customizable – Expandable with multiple mounts (camera, radar) for advanced operations.
Specifications:
Component | Details |
---|---|
Item Type | Spraying Drone |
Propeller Type | 34 inch |
Motors | Hobbywing X9 (150KV) |
ESC Requirement | 80A FOC ESC (not included) |
Loading Capacity | 46.5 kg |
Battery | 14S LiPo |
Wheelbase | 1854 mm |
Frame Size (Open) | 2717 x 2717 x 660 mm |
Frame Size (Folded) | 1224 x 1203 x 660 mm |
Shipping Weight | 23.5 kg |
Shipping Dimensions | 80 × 60 × 55 cm |
Warranty:
15-Day Warranty covering manufacturing defects only. Warranty void if the product shows signs of misuse, tampering, static discharge, water/fire damage, chemical exposure, or modification (like soldering).
