APM 2.8 Upgraded Flight Controller kit with GPS Module Combo Kit (NDK14)

Original price was: ₹10,780.00.Current price is: ₹10,190.00.

  • Upgraded APM 2.8 Flight Controller with built-in or external compass option
  • Ideal for FPV drones and rovers with high precision navigation
  • Includes GPS module, power module, vibration damping mount, and antenna base
  • Supports multiple GNSS systems (GPS, GLONASS, BeiDou)
  • Designed for enhanced stability and accurate positioning
  • Compatible with APM 2.5, 2.6, 2.8, and Pixhawk controllers
Product Code: NDK14 Categories: , Tags: , , , , , , , , , , , ,

Description

The NDK14 – APM 2.8 Flight Controller Kit by LOFTY AGROTECH is a high-precision autopilot system designed for multi-copters, fixed-wing aircraft, and rovers. This upgraded version of the APM 2.8 flight controller offers built-in or external compass support, giving users flexibility in different setups. It includes an NEO-M8N GPS module, providing accurate position tracking with support for GPS, GLONASS, and BeiDou satellite systems.

The shock-absorbing mount effectively reduces vibrations, ensuring stable flight performance and precise control. The power module provides a clean power supply to the APM controller while monitoring voltage and current consumption.

With high-precision sensors, an upgraded barometer, and a powerful ATMEGA2560 processor, this kit is ideal for DIY drone enthusiasts and professionals looking for an advanced flight control system.

Why Choose NDK14 – APM 2.8 Kit?

✔ Upgraded Autopilot System: APM 2.8 with built-in compass support
✔ Enhanced Navigation: NEO-M8N GPS module with high-accuracy tracking
✔ Vibration Reduction: Glass fiber anti-vibration shock absorber mount
✔ Stable Power Supply: APM 2.5/2.6/2.8 Pixhawk power module included
✔ Flexible Installation: Compatible with various drone platforms

Specifications & Features

APM 2.8 Flight Controller:

  • Needle: Straight
  • Power supply: LP2985-3.3
  • Max voltage: 16V
  • 47uF tantalum capacitor for stability
  • Ports: MUX (UART0, UART2, I2C, OSD – default output)
  • Arduino Compatible
  • Built-in 3-axis gyro, accelerometer, and high-performance barometer
  • 4MB onboard DataFlash for automatic logging
  • Upgraded barometric pressure sensor: MS5611-01BA03
  • Atmel ATMEGA2560 and ATMEGA32U-2 chips for processing & USB functions

Glass Fiber Anti-vibration/Shock Absorber Mount:

  • Material: Glass fiber
  • Supports multiple flight controllers: APM 2.5/2.6/2.8, KK, MWC, Pixhawk 2.4
  • Package Weight: 24 gm
  • Upper Frame Size: 90 x 60 x 2 mm
  • Lower Frame Size: 100 x 70 x 2 mm
  • Shock Absorber Height: 10 x 12 mm

NEO-M8N GPS Module:

  • 72-channel u-blox M8 engine
  • Supports GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1
  • Position accuracy: 2.0m CEP
  • Cold Start: 26 seconds
  • Tracking Sensitivity: –167 dBm
  • Built-in RTC crystal for better timing accuracy
  • Active and passive antenna support
  • Integrated data-logger for position, velocity, and time tracking

GPS Folding Base Antenna Set:

  • Material: CNC aluminum alloy & carbon fiber rod
  • Rod Diameter: 4mm
  • Rod Length: 14cm
  • GPS Plate Diameter: 40mm
  • Base Plate Diameter: 35mm
  • Mounting Hole Spacing: 16-35mm
  • Weight: 20g
  • Color: Anodized black

APM 2.5/2.6/2.8 Pixhawk Power Module V1.0:

  • Max Input Voltage: 28V
  • Max Current Sensing: 90A
  • Voltage & Current Measurement: Configured for 5V ADC
  • Switching Regulator Output: 5.3V, 3A max
  • 6-pos DF13 cable for direct connection to APM PM port
  • Supports up to 6S LiPo battery

Package Includes:

✔ 1 x APM 2.8 Flight Controller
✔ 2 x Connecting Wires
✔ 1 x Glass Fiber Flight Controller Anti-vibration/Shock Absorber Set
✔ 1 x NEO-M8N GPS Module with Translucent Shell
✔ 1 x GPS Folding Base Antenna Set
✔ 1 x APM 2.5/2.6/2.8 Pixhawk Power Module V1.0

Product Details:

Item Type: Kit
Input Voltage: 28V
Operating Current: 90A
Battery Support: 6S
Shipping Weight: 0.6 kg
Shipping Dimensions: 15 × 10 × 6 cm

Warranty – 15 Days Against Manufacturing Defects

This item is covered under a 15-day warranty from the date of delivery against manufacturing defects only. The warranty is provided for LOFTY AGROTECH customers, ensuring high product quality. Replacement will be provided for verified manufacturing defects.

What Voids the Warranty?

❌ Misuse, tampering, or static discharge
❌ Accidental damage (water, fire, chemicals, etc.)
❌ Soldering or modifying the product in any way
