EMAX RS2205 KV2300 Brushless DC Motor for FPV Racing Drone ? Black Cap (CW)

  • High-performance 2300KV Race Spec brushless motor

  • Produces up to 1024g thrust with 4S LiPo

  • Advanced cooling fin design lowers temperature by up to 30%

  • Built with N52 magnets and Japanese NMB bearings

  • 15mm extended shaft fits most 5mm propellers

  • Lightweight (30g), compact and race-ready

  • CW rotation with CCW (left-handed) thread for secure prop fit

Category: Tags: , , , , , , , , , , , , , , ,

Description

Detailed Description

We at NDK21 BY LOFTY AGROTECH are excited to introduce the high-performance EMAX RS2205 KV2300 Brushless DC Motor, a part of the Race Spec series, purpose-built for FPV racing drones. Whether you’re gearing up for your next race or building a custom quad for high-speed aerial agility, this motor is engineered to deliver exactly what you need — power, precision, and speed.

Manufactured by EMAX, a globally recognized name in quality brushless motors, the RS2205 is imported directly from the original EMAX factories and goes through rigorous in-house quality checks before reaching you. With integrated cooling fins, this motor self-cools during operation, reducing the operating temperature by up to 30% — a crucial feature for long, aggressive flight sessions.

Inside, it’s built with top-tier N52 neodymium magnets, genuine Japanese NMB bearings, and high-purity copper windings to ensure reliability and vibration-free operation. Each unit is dynamically balanced at the factory and features a 15mm extended prop shaft, allowing compatibility with nearly all 5mm bore propellers.

When combined with high-performance Orange Propellers and a 4S LiPo battery, the RS2205 produces up to 1024g of thrust, giving your racing drone the edge in speed and responsiveness. Its CW rotation and left-handed thread (CCW) provide a secure propeller lock during high-speed spins.

Looking for the CCW version of this motor? Click here
Explore all Drone Motors here
Browse compatible Propellers here
Find top-quality ESCs here

Technical Specifications:

  • Motor KV (RPM/V): 2300

  • Motor Type: Brushless Outrunner

  • Model No.: RS2205

  • Compatible LiPo Batteries: 3S to 4S

  • Framework: 12N14P

  • Maximum Thrust: 1024g

  • Shaft Diameter: 3 mm

  • Length: 31.7 mm

  • Width: 27.9 mm

  • Weight: 30 g

  • Shipping Weight: 0.033 kg

  • Shipping Dimensions: 20 × 5 × 3 cm

Package Includes:

  • 1 × EMAX RS2205 KV2300 Brushless DC Motor (CW)

  • 1 × Locknut

  • 2 × Sets of Motor Mounting Screws (for 3mm and 4mm frames)
