The C945 NPN Transistor SOT-23 SMD Package is a low-noise silicon epitaxial transistor designed for general-purpose amplification and switching in compact surface-mount circuits. Its stable gain, low leakage, and fast response make it suitable for audio preamps, signal processing, driver stages, and low-current switching applications.
CLICK HERE FOR DATASHEET
10 × C945 NPN Transistor - SOT-23 SMD Package
| Collector-Emitter Voltage (VCEO) | 50V |
|---|---|
| Collector-Base Voltage (VCBO) | 60V |
| Emitter-Base Voltage (VEBO) | 5V |
| Collector Current (IC) | 150mA |
| DC Current Gain (hFE) | 130–400 |
| Collector-Emitter Saturation Voltage (VCE(sat)) | ≤0.3V (IC = 100mA) |
| Base-Emitter Voltage (VBE) | ≤1.4V |
| Transition Frequency (fT) | 150MHz |
| Total Power Dissipation (Ptot) | 200mW |
| Thermal Resistance Junction-to-Ambient (RθJA) | 625°C/W |
| Operating Junction Temperature (TJ) | -55°C to +150°C |
