The DALY LiFePO4 16S 48V 100A BMS is a high-performance battery management system designed to protect and manage lithium iron phosphate (LiFePO4) battery packs configured in a 16-series (16S) arrangement, totaling 48V nominal voltage. It ensures safe and efficient operation by offering protections against overcharge, over-discharge, overcurrent, short-circuit, and high temperatures.
Engineered with waterproof, dustproof, and vibration-resistant construction, this BMS is ideal for high-power applications such as solar energy storage systems, electric bikes, scooters, power tools, and battery packs for industrial or DIY projects. The system includes features like intelligent passive balancing and accurate voltage monitoring for optimal battery life and safety.
Features of DALY LiFePO4 16S 48V 100A BMS:
Specifications of DALY LiFePO4 16S 48V 100A BMS:
Package Includes:
1 × DALY LiFePO4 16S 48V 100A Waterproof Battery Management System
| Battery Type | LiFePO4 (Lithium Iron Phosphate) |
|---|---|
| Series | 16S (16 cells in series) |
| Nominal Voltage | 48V |
| Continuous Discharge Current | 100A |
| Charging Current | 60A |
| Overcharge Detection Voltage | 3.65V ± 0.05V (per cell) |
| Over-discharge Voltage | 2.5V ± 0.05V (per cell) |
| Overcurrent Detection | 101A |
| Balance Function | Yes (Passive Balancing) |
| Balance Voltage | 3.20V (per cell) |
| Short Circuit Protection | Yes (with automatic recovery) |
| Operating Temperature | -15°C to 60°C |
| Waterproof Rating | IP65 |
| Dimensions (Approx.) | 125mm × 65mm × 13mm |
| Weight | 220g |
| IC Chip | Integrated Protection Circuit |
