The ES2J Super Fast recovery Rectifier Diode - DO-214AC SMD Package is designed for efficient AC to DC rectification in compact surface-mount applications. Its glass passivated chip junction provides stable, low-loss operation with ultrafast recovery and high surge capability. Ideal for high-frequency power supplies, converters, and automated assembly circuits.
CLICK HERE FOR DATASHEET
10 pcs × ES2J Super Fast Recovery Rectifier Diode - DO-214AC SMD Package
| Maximum Repetitive Peak Reverse Voltage (VRRM) | 600 V |
|---|---|
| Maximum RMS Voltage (VRMS) | 420 V |
| Maximum DC Blocking Voltage (VDC) | 600 V |
| Average Forward Rectified Current (IF(AV)) | 2.0 A |
| Peak Forward Surge Current (IFSM) | 50 A |
| Instantaneous Forward Voltage (VF) at 2 A | 1.70 V |
| Reverse Current (IR) at 25°C | 5 µA |
| Reverse Current (IR) at 125°C | 50 µA |
| Reverse Recovery Time (trr) | 35 ns |
| Typical Junction Capacitance (CJ) | 18 pF |
| Thermal Resistance Junction to Lead (RθJL) | 35 °C/W |
| Operating and Storage Temperature Range (TJ, TSTG) | -55°C to +150°C |
