The SS8550 PNP Transistor - SOT-23 SMD Package is a high-gain, general-purpose transistor designed for medium current and low-voltage switching applications. With low saturation voltage and high current handling capacity, it ensures efficient performance in compact PCB layouts. Ideal for audio amplification, driver stages, and complementary use with NPN SS8050 transistors.
CLICK HERE FOR DATASHEET
10 × SS8550 PNP Transistor - SOT-23 SMD Package
| Collector-Base Voltage (VCBO) | -40V |
|---|---|
| Collector-Emitter Voltage (VCEO) | -25V |
| Emitter-Base Voltage (VEBO) | -5V |
| Collector Current (IC) | -1.5A |
| Collector Power Dissipation (PCM) at 25°C | 0.3W |
| Junction Temperature (TJ) | -55°C to +150°C |
| Storage Temperature (TSTG) | -55°C to +150°C |
| Collector-Base Breakdown Voltage (V(BR)CBO) | -40V |
| Collector-Emitter Breakdown Voltage (V(BR)CEO) | -25V |
| Emitter-Base Breakdown Voltage (V(BR)EBO) | -5V |
| Collector Cutoff Current (ICBO) | -0.1µA |
| Collector Cutoff Current (ICEO) | -0.1µA |
| Emitter Cutoff Current (IEBO) | -0.1µA |
| DC Current Gain (hFE1) at -100mA | 120 to 350 |
| DC Current Gain (hFE2) at -800mA | Min 40 |
| Collector-Emitter Saturation Voltage (VCE(sat)) | -0.5V |
| Base-Emitter Saturation Voltage (VBE(sat)) | -1.2V |
| Transition Frequency (fT) | 100MHz |
