| Stator Diameter | 22mm |
|---|---|
| Stator Thickness | 12mm |
| No. of Stator Arms | 12 |
| No. of Rotor Poles | 14 |
| Motor Kv | 980 |
| No-Load Current (A/10V) | 0.7A |
| Recommended Prop(inch) | 9450 |
| Motor KV (RPM/V): | 980 |
| Motor Type: | Brushless Motor |
| No. of Stator Poles | 14 |
| Motor Resistance | 123mΩ |
| Continuous Current (A): | 20A/30s |
| Max. Power (W) | 330W |
| Motor Weight (g) | 56 |
| Outer Diameter (mm): | 27.5 |
| Motor Body Length (mm): | 40 |
| Required ESC (A) | 20 |
| GTIN | 192948270642 |
| Shipping Weight | 0.067 kg |
| Shipping Dimensions | 8 × 5 × 4 cm |
