Sunny Sky V2806 KV650 Brushless Motors

Stator Diameter: 28mm Stator Thickness: 6mm No.of Stator Slots: 12 No.of Rotor Poles: 14 Motor Kv: 650 No-load current: 0.4A/10V Recommended Prop(inch): EOLO CN11*4.5/CN12*5

Specifications

Stator Diameter	28mm
Stator Thickness	6mm
No.of Stator Slots	12
No.of Rotor Poles	14
Motor Kv	650
No-load current	0.4A/10V
Recommended Prop(inch)	EOLO CN11*4.5/CN12*5
Motor KV (RPM/V):	650
Motor Type:	Brushless Motor
No. of Stator Arms	12
No. of Stator Poles	14
No-Load Current (A/10V)	0.4A/10V
Motor Resistance	227mΩ
Continuous Current (A):	16A/180s
Max. Power (W)	250W
Motor Weight (g)	47
Diameter (mm):	35 (Outside )
Motor Body Length (mm):	18
Shipping Weight	0.145 kg
Shipping Dimensions	12 × 9 × 5 cm
