| Operating Voltage | 24/48V |
|---|---|
| Rated Torque(Nm) | 8.3 |
| Peak Torque(Nm) | 24.8 |
| Gear Reduction ratio | 10:1 |
| Motor Type: | Brushless Motor |
| Rated Torque (N-m): | 8.3 |
| No. of Pole-Pair | 21 |
| Peak Torque (Nm) | 24.8 |
| Max Speed @Rated Torque(rpm) | 200/400 |
| Resistance Phase to Phase | 272±5 mΩ |
| Inductance Phase to Phase | 113±10uH |
| Rated current (mA): | 8.8A |
| Peak Current (A) | 26.1A |
| Max torque weight ratio | 47 .6 |
| Gear Reduction Ratio: | 10:01 |
| OD(mm) | Φ89 |
| Height (mm) | 50.2 |
| Weight (g): | 521 |
| Shipping Weight | 0.72 kg |
| Shipping Dimensions | 12 × 12 × 6 cm |
