| Max Thrust | 9.5 Kg |
|---|---|
| Weight | 380 gms |
| IP Rating | IP45 |
| Design Life | 1000 Hrs |
| Nominal Voltage | 24V - 48V (6S-12S) |
| Propeller Compatibility | 22 CF Propeller |
| Country of Origin | India |
| Motor KV (RPM/V): | 340 |
| Torque Constant KT | 0.0407 Nm/A @ 4508 rpm |
| Continuous Current (A): | 40 |
| Max. Power (W) | 900 |
| Voltage Rating (V): | 44V to 52V (12S LiHV) |
| No. of Stator Poles | 24S (24S28P) |
| No. of Bearings | Triple, 626-2Z |
| Output Shaft Diameter (mm) | ø6 |
| Motor diameter (mm) | ø69.5 |
| Motor Length (mm): | 47.7 |
| Motor Weight (g) | 420 |
| Mounting holes | 90 deg: 4xM4 ф30 mm, Depth 5 mm; 4xM4 ф40 mm, Depth 5 mm; 4xM4 ф50 mm, Depth 6 mm |
| Compatible Prop (inch): | 22 CF Propeller |
| Shipping Weight | 0.46 kg |
| Shipping Dimensions | 12 × 13 × 11 cm |
