| Motor Type: | FPV Motor |
|---|---|
| Model Name: | XING-E Pro 2306 Motor |
| Motor KV (RPM/V): | 1700 |
| Weight (g): | 33.6 |
| Dimensions (L x W x H) mm | φ29*18.7 |
| Input Voltage | 25.2V |
| Peak Current (A) | 36.66A |
| Watts | 920.2W |
| Mounting holes | 16*16 φ3mm |
| Shaft Diameter | 5mm |
| Shaft Length | 13.5 mm |
| Magnets | N52H Curved |
| Configuration: | 12N14P |
| Bearing Type | NSK |
| Bearing Size | φ9*φ4*4 |
| Winding Type | Single Strand copper winding |
| Shipping Weight | 0.044 kg |
| Shipping Dimensions | 5 × 5 × 5 cm |
